Pourable two-part silicone is a different animal to the silicone-caulk putty method. You weigh it, mix it, pour it and let it find its own level, which is what lets it pick up detail a putty press never will.

Red Rocking Bird builds a simple housing, sticks the master pieces to a clear base and fills the space around them. The one thing worth respecting is the weighing - this is a ratio product, and eyeballing it gives you a mold that never fully cures.

Free printable

Print the steps and supply list for this project

One page you can take to the table. Free with a free account, no password.

Get the free printable

What you'll need

Free, for this project

Get this checklist by email

  • All 10 tools and materials, with tick boxes
  • A link to print all 10 steps on paper, to keep by you while you craft

No password. The whole tutorial stays free on this page.

Quick answer

Cast your own silicone molds with pourable two-part rubber. A medium project: about 45 minutes, plus 24 hours to dry or set. Materials cost about $25 to $45. You need 10 things, including Two-part silicone rubber, Mold housing or plastic box and Double-sided tape. The 10 steps start with pick a Housing, seal the Base, fit a Clear Base, weigh the Two Parts, stir It Thoroughly, set Your Masters In Place, pour the Silicone, cure It Level and release the Mold.

Step-by-step guide

10 steps, about 11 minutes. Tap a picture to jump to that step. Your progress saves automatically.

Tick each step off as you go.

  1. Step 1: Pick a Housing

    Watch this step · 0:20

    You need something to cast into. A simple plastic mold housing works, and it does not have to be anything purpose-made.

    Whatever you use just needs straight sides and a base you can seal, so the liquid silicone cannot escape.

    Back to all steps

  2. Step 2: Seal the Base

    Watch this step · 0:55

    Run double-sided tape all the way around the rim of the housing, checking there are no gaps in the run.

    Some people hot-glue the housing down instead. Tape is enough and it comes apart far more easily afterwards.

    Back to all steps

  3. Step 3: Fit a Clear Base

    Watch this step · 1:28

    Press a sheet of acetate or wide clear tape across the taped rim to close the bottom.

    A clear base does two jobs - it seals the housing, and it gives you a sticky surface to mount your master pieces onto.

    Tip:

    Check the seal all the way round before you mix anything. Silicone finds every gap.

    Back to all steps

  4. Step 5: Stir It Thoroughly

    Watch this step · 3:05

    Combine the two parts with a wooden stick and keep going. Most kits ask for three to five minutes.

    Scrape the sides and the bottom of the cup as you stir. Unmixed streaks left in the corners will not cure.

    Tip:

    A good kit mixes smoothly and pours almost bubble-free, so do not rush this part looking for shortcuts.

    Back to all steps

  5. Step 6: Set Your Masters In Place

    Watch this step · 3:35

    Stick the pieces you are moulding down onto the clear base inside the housing.

    Pack in as many as the space will take. Silicone is the expensive part, so every gap you leave empty is money poured away.

    Tip:

    Anything hollow will float up once the silicone goes in. Stick those down firmly or weight them.

    Back to all steps

  6. Step 7: Pour the Silicone

    Watch this step · 4:10

    Pour the mixed silicone into the housing in a thin steady stream from one corner, letting it flow around the masters.

    Pouring from height and in a thin stream helps break any bubbles on the way down.

    Tip:

    Leave it clear if you plan to cure UV resin in the finished mold. Pigment blocks the light.

    Back to all steps

  7. Step 8: Cure It Level

    Watch this step · 5:00

    Set the filled housing somewhere genuinely level and leave it for about 24 hours.

    A levelling table is ideal but any flat shelf works. Cure it on a slope and the back face of your mold sets at an angle.

    Back to all steps

  8. Step 9: Release the Mold

    Watch this step · 6:06

    Peel the housing away from the cured block and pop the mold out. It should release with gentle pressure - run a knife around the edge only if it sticks.

    Flex it open and check the cavity picked up the detail you wanted before you cast anything into it.

    Back to all steps

How to Make a Resin Suncatcher

Keep going

How to Make a Resin Suncatcher

Keep going with resin art

More on this topic, picked for this silicone mold.

You reached the last step

Save this project to come back to it

Your ticked steps, the free printable and your other saved makes, together in My Projects. Free, no password.

You tapped Save

Save this project for later

We'll email you a link, no password.

How to Make a Silicone Mold

  • Your saved projects in one list
  • Your ticked steps on any device

Check your inbox for an email from us. Not there? Look in your spam folder.

Free printable

Printable sheet and shopping list for this project

The bonus is hidden until you sign up.

Free with a free account, no password. Every step above stays open to everyone.

Products Used

The Checklist

How to Make a Silicone Mold

Tools
4
Materials
6
Steps
10
Video
11 min

Tools we recommend

As an Amazon Associate we earn from qualifying purchases. Links on this page may be affiliate links - clicking them and buying doesn't change your price, but helps support Crafting Step by Step.

Tags

The Crafter's Weekly

New resin art tutorials, every Sunday

One short email with the week's best step-by-step guides. Free, no spam, unsubscribe anytime.

Test your knowledge

Did the lesson stick? Start with this one.

5 questions covering what you just read. No signup, no score saved, and you can stop after this one.

Question 1 of 5

What must the mold housing have?

Quick reference

Key takeaways from How to Make a Silicone Mold

5 questions, answers, and one-line explanations. Tap to expand.

  1. 1.What must the mold housing have?

    Answer: Straight sides and a sealed base

    The liquid silicone just needs somewhere it cannot escape from.

  2. 2.Why fit a clear acetate base across the taped rim?

    Answer: It seals and holds masters in place

    The clear sheet closes the bottom and gives a sticky surface to mount onto.

  3. 3.Why weigh part A and part B on a digital scale?

    Answer: It is a ratio product that must be exact

    Measuring by eye leaves you a mold that stays tacky and never cures.

  4. 4.Why scrape the sides and bottom while stirring?

    Answer: Unmixed streaks will not cure

    Corners are where the two parts hide from the stirring stick.

  5. 5.Why pack in as many masters as the housing will take?

    Answer: Silicone is the expensive part

    Every empty gap is silicone you paid for and cannot cast into.
